- XCUT-100
Products
XCUT-100
Double-sided adhesive tape is usable
The construction of a new scissor cutting can apply on non-woven tapes
- Cutting Length
- 30～9999mm
(Manual Mode)
80～9999mm
(Auto Mode)
- Tape Width
- 20～100mm
Features
XCUT-100RP is available to peel backing paper during operation.
| Specifications | |
|---|---|
| Cutting Length | 30～9999mm (Manual Mode) 80mm～9999mm (Auto Mode) |
| Tape Width | 20～100mm |
| Max. Roll Diameter | 200mm |
| Feeding Speed | 48pcs/min. (Craft tape in 100mm cutting length) 240mm/Sec. (Craft tape) |
| Rated Voltage | AC 100-240V 50/60Hz 45W |
| Dimension | 279×266×241mm (W×H×D) |
| Weight | 11kg (Excluding Bobbin) |
*Some of usable tapes may not cut as depends on the material and tape brand.
*Cutting length may be beyond cutting tolerance as depends on the type of tapes.
*Specifications are subject to change without prior notice.
Ex. Safety Cover, Arm Stand and Removing Liner Paper etc.
Customized Solutions
Depending on your usage and using tapes.
